Titanium Grade 5 Powder (Ti-6Al-4V)
Titanium Grade 5 Powder (Ti-6Al-4V) Supplier and Exporter
Titanium Grade 5 (Ti-6Al-4V) powder (R56400) is a plasma atomised or plasma rotating electrode, for sphericity and low satellite content alpha-beta titanium alloy feedstock for additive manufacturing, supplied to ASTM F2924 (PBF) in 5-25 µm, 15-45 µm, 15-53 µm, 45-105 µm, 53-105 µm, 45-150 µm, 53-150 µm size fractions.
The most used titanium alloy in manufacturing, and the reason printed titanium parts exist at all: roughly the strength of steel at 60% of the weight.
Ti-6Al-4V Grade 5 Powder at a Glance
| UNS / designation | R56400 |
|---|---|
| Werkstoff (W.Nr.) | 3.7165 |
| Alloy family | Alpha-beta titanium alloy |
| Feedstock specification | ASTM F2924 (PBF), ASTM B348 for the wrought equivalent |
| Size fractions | 5-25 µm · 15-45 µm · 15-53 µm · 45-105 µm · 53-105 µm · 45-150 µm · 53-150 µm Held in stock or arranged with the manufacturer, depending on quantity. |
| Most common cut | 45-105 µm (EBM) |
| Production route | Plasma atomised or plasma rotating electrode, for sphericity and low satellite content |
| Density | 4.43 g/cm3 |
| Melting range | 1604-1660 C |
| Composition | 5.5-6.75% aluminium and 3.5-4.5% vanadium, with oxygen to 0.20% maximum. |
| Minimum order | 5 kg |
| Lead time | 7 days from order confirmation |
| Price | INR 12,000 – 21,000 per kg. Indicative USD 141 – 247 per kg; quoted against grade, form, size and quantity. |
What Properties Does Printed Ti-6Al-4V Grade 5 Reach?
Printed properties depend on the heat treatment, not just the alloy, so they are given per condition.
| Condition | Tensile strength | Yield strength | Elongation | Hardness |
|---|---|---|---|---|
| As built | 1200-1400 MPa | 1050-1200 MPa | 6-12% | 35-40 HRC |
| Stress relieved at 704 C | 1000-1100 MPa | 900-1000 MPa | 12-18% | 30-35 HRC |
| HIP | 950-1050 MPa | 850-950 MPa | 14-20% | 30-35 HRC |
As-built titanium is strong but low in ductility, because of the martensitic alpha-prime structure. Stress relief converts it; HIP additionally closes porosity for fatigue-critical parts.
Which Processes Can Ti-6Al-4V Grade 5 Powder Be Used In?
| LPBF | EBM | DED / cladding | MIM | Binder jetting | Thermal spray |
|---|---|---|---|---|---|
| Yes | Yes | Yes | Yes | Limited | Limited |
What Is Ti-6Al-4V Grade 5 Powder Used For?
Aerospace structure and brackets, motorsport components, marine hardware and industrial tooling.
Post-processing
Stress relief in vacuum or argon, then HIP to close internal porosity for fatigue-critical parts.
Should I use Titanium Grade 5 or Grade 23 powder?
They share a composition; Grade 23 simply holds oxygen, iron and carbon to tighter limits. Grade 5 suits aerospace and industrial parts where strength governs. Grade 23 is for implants and damage-tolerant parts, because the lower interstitials buy fracture toughness and ductility.
Characterisation and Packing
Each batch is supplied with chemical analysis, particle size distribution by laser diffraction to ASTM B822, apparent and tap density, and flow rate by Hall or Carney funnel. Morphology imaging, oxygen and nitrogen analysis and reporting to ISO/ASTM 52907 are available where your qualification requires them.
Powder is packed under argon in sealed containers with desiccant, labelled with lot number, alloy, particle size cut and date of atomisation.
Ti-6Al-4V Grade 5 Powder: Frequently Asked Questions
Request a Quotation for Titanium Grade 5 Powder (Ti-6Al-4V)
Send the particle size cut, the quantity and the process you are running, and we will quote with lead time and the characterisation data you need. Call +91 7977 88 6611 or email info@auricoalloys.com.
Request a sample Contact Sales All Titanium powders Ti-6Al-4V Grade 5 in wrought form
