Aurico Alloys LLP supplies Sanicro 35 seamless tube and pipe (UNS N08935) to ASTM B163 and ASTM B677, cut to length from Mumbai and exported worldwide.
Tube and pipe is the form Alleima makes itself — the company owns the SANICRO trademark and developed the grade — and it is delivered in the solution annealed condition. Plate and sheet in the same alloy are rolled by Outokumpu under licence.
The alloy exists to close a gap. Below it, the 6% molybdenum super-austenitics are marginal in hot seawater; above it, a nickel alloy costs more than the duty needs. Sanicro 35 carries 27% chromium, 35% nickel, 6.5% molybdenum and 0.3% nitrogen, which puts its pitting resistance in 6-moly territory while the nickel content handles the chloride stress-corrosion cracking that ends the life of leaner grades.
Sizes and Specifications
| Grade | Sanicro 35 |
|---|---|
| UNS number | N08935 |
| Tube specification | ASTM B163 |
| Pipe specification | ASTM B677 |
| Code approvals | ASME Code Case 2982 (Section VIII, Divisions 1 and 2); ASME Code Case 3089 (Section I); TUV pre-approval for Particular Material Appraisal, file 1326W043219 |
| Sour service | NACE MR0175 / ISO 15156-3:2015 for type 4a and type 4c materials; ANSI/NACE MR0103 / ISO 17495-1:2016 |
| Producing mill | Alleima AB |
| Condition | Seamless, solution annealed |
| Size range | Quoted against the mill programme in force at the time of enquiry – send outside diameter, wall thickness, length and quantity and we will confirm availability and lead time. |
| Certification | EN 10204 3.1 mill test certificate; 3.2 and third-party inspection on request |
Equivalent Grades & Standards
| Property | Value |
|---|---|
| UNS number | N08935 |
| Werkstoff / EN number | — |
| EN designation | — |
| Density | 8.10 g/cm3 |
| Modulus of elasticity (20 °C) | 190 GPa |
| Thermal conductivity (20 °C) | 10.0 W/m·°C |
| Electrical resistivity (20 °C) | 1.0 µΩ·m |
| Specific heat (20 °C) | 450 J/kg·°C |
| Coefficient of expansion (30-100 °C) | 14.0 µm/m·°C |
| Pipe and tube specification | ASTM B163 / B677 |
Identifiers and physical constants for Sanicro 35. A dash means no such designation is published for this grade.
Chemical Composition
Nominally 27% chromium, 35% nickel and 6.5% molybdenum with 0.3% nitrogen and a small copper addition. Set against Alleima's older Sanicro 28, the molybdenum is nearly doubled and the nitrogen raised threefold, which is where the extra chloride performance comes from.
| Element | Min (%) | Max (%) |
|---|---|---|
| Carbon (C) | — | 0.030 |
| Silicon (Si) | — | 0.5 |
| Manganese (Mn) | 0.8 nominal | |
| Phosphorus (P) | — | 0.030 |
| Sulfur (S) | — | 0.020 |
| Chromium (Cr) | 27 nominal | |
| Nickel (Ni) | 35 nominal | |
| Molybdenum (Mo) | 6.5 nominal | |
| Copper (Cu) | 0.2 nominal | |
| Nitrogen (N) | 0.3 nominal | |
Composition for Sanicro 35. Figures given as a range or a maximum are limits and those marked nominal are not; none of them are measured values for a lot; the mill test certificate supplied with your order states the actual analysis.
Mechanical and Physical Properties
In the solution annealed condition at 20°C, Alleima publishes minima of 425 MPa proof strength (Rp0.2) and 750 MPa tensile strength for tube to ASTM B163, with 35% elongation. Pipe to ASTM B677 is 400 MPa proof strength against the same 750 MPa tensile and 35% elongation. That is high strength for an austenitic material, and it is what allows thinner walls at a given pressure.
Weldability is good with nickel-alloy consumables. Alleima recommends TIG welding (GTAW) at a maximum heat input of 1.0 kJ/mm and a maximum interpass temperature of 100°C, using a stringer technique; preheating and post-weld heat treatment are normally not necessary.
Industry Applications
Why this grade
Alleima developed Sanicro 35 for service where seawater is used for cooling or heating, and it has good resistance to hydrochloric acid compared with stainless steels of lower chromium and molybdenum content. In hydrochloric acid it holds its isocorrosion line further out than Sanicro 28, 904L or 316 — the practical difference being service in acid concentrations and temperatures where those three are already through-wall.
| Industry | Typical use |
|---|---|
| Power and desalination | Seawater-cooled condenser and heat exchanger tubing, brine heaters. |
| Refining | Overhead condensers and exchanger bundles in chloride-bearing and sour condensate service. |
| Oil and gas | Sour-service lines and downhole tubing certified as NACE MR0175 / ISO 15156-3 type 4a and 4c material. |
| Chemical processing | Acid service piping, particularly hydrochloric and mixed-acid duty. |
| Boilers and pressure vessels | Section I and Section VIII work under ASME Code Cases 3089 and 2982. |
Testing and Certification
Every consignment ships with an EN 10204 3.1 mill test certificate stating heat number, chemical analysis and mechanical properties. Depending on the specification we can add positive material identification, ultrasonic and eddy-current testing, hydrostatic testing, intergranular corrosion testing to ASTM G28 or A262, and third-party inspection release from Lloyd's Register, Bureau Veritas, SGS or TUV.
Aurico Alloys LLP operates an ISO 9001:2015 quality management system, and can certify material to NACE MR0175 / ISO 15156 for sour service where the grade permits.
Frequently Asked Questions
Request a Quotation
Send your size, quantity and specification and we will come back with price and lead time, usually the same working day. Call +91 7977 88 6611 or email info@auricoalloys.com.
