Sanicro 35 Plates and Sheets Supplier, Stockist and Exporter
Table of Contents
Aurico Alloys LLP supplies Sanicro 35 plate and sheet (UNS N08935) to ASTM B625, cut to size from Mumbai and exported worldwide.
The flat product is rolled by Outokumpu under a licence agreement with Alleima, who owns the SANICRO trademark and makes the grade as seamless tube and pipe. It is the same alloy either way; the difference is the production route and therefore which mill's certificate arrives with the material.
Sanicro 35 was developed to close the gap between the 6% molybdenum super-austenitic stainless steels and the nickel alloys. At roughly 27% chromium, 35% nickel, 6.5% molybdenum and 0.3% nitrogen it keeps the pitting resistance of a 6-moly grade while the nickel content lifts its chloride stress-corrosion resistance well past what 254 SMO or AL-6XN will give.
Sizes and Specifications
| Grade | Sanicro 35 |
|---|---|
| UNS number | N08935 |
| Flat product specification | ASTM B625 |
| Code approval | ASME Code Case 2982, Boiler and Pressure Vessel Code Section VIII, Divisions 1 and 2 |
| Producing mill | Outokumpu, under licence from Alleima AB |
| Condition and finish | Solution annealed and pickled; hot-rolled plate and cold-rolled sheet, 2B or 1D finish to order |
| Size range | Quoted against the rolling programme in force at the time of enquiry – send thickness, width, length and quantity and we will confirm what is available and the lead time. |
| Processing | Plasma and waterjet cutting, shearing, edge preparation and cut blanks |
| Certification | EN 10204 3.1 mill test certificate; 3.2 and third-party inspection on request |
Equivalent Grades & Standards
| Property | Value |
|---|---|
| UNS number | N08935 |
| Werkstoff / EN number | — |
| EN designation | — |
| Density | 8.10 g/cm3 |
| Modulus of elasticity (20 °C) | 190 GPa |
| Thermal conductivity (20 °C) | 10.0 W/m·°C |
| Electrical resistivity (20 °C) | 1.0 µΩ·m |
| Specific heat (20 °C) | 450 J/kg·°C |
| Coefficient of expansion (30-100 °C) | 14.0 µm/m·°C |
| Plate, sheet and strip specification | ASTM B625 |
Identifiers and physical constants for Sanicro 35. A dash means no such designation is published for this grade.
Chemical Composition
Nominally 27% chromium, 35% nickel and 6.5% molybdenum with 0.3% nitrogen. The nitrogen is what lets a grade of this chromium and molybdenum content reach its pitting resistance without the cost of a full nickel alloy.
| Element | Min (%) | Max (%) |
|---|---|---|
| Carbon (C) | — | 0.030 |
| Silicon (Si) | — | 0.5 |
| Manganese (Mn) | 0.8 nominal | |
| Phosphorus (P) | — | 0.030 |
| Sulfur (S) | — | 0.020 |
| Chromium (Cr) | 27 nominal | |
| Nickel (Ni) | 35 nominal | |
| Molybdenum (Mo) | 6.5 nominal | |
| Copper (Cu) | 0.2 nominal | |
| Nitrogen (N) | 0.3 nominal | |
Composition for Sanicro 35. Figures given as a range or a maximum are limits and those marked nominal are not; none of them are measured values for a lot; the mill test certificate supplied with your order states the actual analysis.
Mechanical and Physical Properties
Alleima describes the grade as having very high mechanical strength for an austenitic material, and publishes minima against its tube and pipe standards rather than against flat product: proof strength 425 MPa and tensile strength 750 MPa for tube to ASTM B163, with 35% elongation, in the solution annealed condition. Plate to ASTM B625 is certified to that standard's own requirements, which are stated on the mill certificate for the heat supplied.
Good weldability with nickel-alloy consumables. Alleima recommends TIG welding at low heat input, with no preheat or post-weld heat treatment normally required.
Industry Applications
Why this grade
Sanicro 35 is specified where a 6-moly stainless is marginal and a nickel alloy is more material than the duty needs. Its resistance to hydrochloric acid runs ahead of stainless steels with lower chromium and molybdenum, and it holds up in seawater used for cooling or heating, which is where the erosion-corrosion resistance matters as much as the pitting resistance.
| Industry | Typical use |
|---|---|
| Power and desalination | Seawater-cooled condenser and heat exchanger shells, tubesheets and waterboxes. |
| Refining | Overhead vessels and exchanger internals in chloride-bearing and sour condensate service. |
| Chemical processing | Acid handling equipment, reaction vessels and scrubber internals. |
| Pollution control | Flue-gas desulphurisation absorbers, ducting and liners. |
| Oil and gas | Sour-service equipment certified to NACE MR0175 / ISO 15156-3 as type 4a and 4c material. |
Testing and Certification
Every consignment ships with an EN 10204 3.1 mill test certificate stating heat number, chemical analysis and mechanical properties, issued by the mill that rolled the plate. Depending on the specification we can add positive material identification, ultrasonic testing, intergranular corrosion testing to ASTM G28 or A262, and third-party inspection release from Lloyd's Register, Bureau Veritas, SGS or TUV.
Aurico Alloys LLP operates an ISO 9001:2015 quality management system, and can certify material to NACE MR0175 / ISO 15156 for sour service where the grade permits.
Frequently Asked Questions
Request a Quotation
Send your size, quantity and specification and we will come back with price and lead time, usually the same working day. Call +91 7977 88 6611 or email info@auricoalloys.com.
