Aurico Alloys LLP supplies nickel alloy round bar from ready stock in Mumbai to customers across India and in more than 40 export markets. Bar is bought to be machined: shafts, stems, fasteners, forged blanks and turned components are all cut from it, and the finish and straightness it arrives in decide how much stock has to come off.
Nickel Alloy covers nickel-base alloys combining high-temperature strength with resistance to oxidising and reducing media. Bar is covered by a different standard from the flat products - ASTM B160 for Nickel 200 / 201 and B164 for Monel 400 against B162 and B127 for sheet - so a bar order must cite the bar specification, not the one on a plate certificate.
Sizes and Specifications
| Size range | Quoted against the mill programme in force at the time of enquiry. Send the sizes you need and we will confirm what is held and what has to be rolled or drawn. |
|---|---|
| Specifications | See the grade-by-grade table below; each grade carries its own standard for this form. |
| Certification | EN 10204 3.1 mill test certificate; 3.2 and third-party inspection on request |
| Origin | Indian and imported mills, fully traceable by heat number |
Specifications by Grade – Rod and bar
A specification is written for a product form. The standards below are the ones that cover rod and bar; the plate, bar and tube specifications for these grades are different documents and are listed on their own pages.
| Grade | UNS | Rod and bar specification |
|---|---|---|
| Nickel 200 | N02200 | ASTM B160 |
| Nickel 201 | N02201 | ASTM B160 |
| Monel 400 | N04400 | ASTM B164 |
| Inconel 600 | N06600 | ASTM B166 |
| Inconel 625 | N06625 | ASTM B446 |
| Incoloy 825 | N08825 | ASTM B425 |
| Hastelloy C-276 | N10276 | ASTM B574 |
| 602 CA | N06025 | ASTM B166 |
| Kovar | K94610 | ASTM F15 / AMS 7727 |
| Waspaloy | N07001 | AMS 5704 / 5706 / 5707 / ASTM B637 |
Grades and International Equivalents
| Grade | UNS | Werkstoff (W.Nr.) |
|---|---|---|
| Nickel 200 / 201 | N02200 / N02201 | 2.4066 / 2.4068 |
| Monel 400 | N04400 | 2.4360 |
| Inconel 600 | N06600 | 2.4816 |
| Inconel 625 | N06625 | 2.4856 |
| Incoloy 800H / 800HT | N08810 / N08811 | 1.4958 / 1.4959 |
| Incoloy 825 | N08825 | 2.4858 |
Chemical Composition
Compositions span commercially pure nickel (99.0% Ni min in Nickel 200) through Ni-Cu (Monel 400: 63% Ni, 31% Cu), Ni-Cr-Fe (Inconel 600: 72% Ni, 15.5% Cr) and Ni-Cr-Mo-Nb (Inconel 625: 58% Ni, 21.5% Cr, 9% Mo, 3.6% Nb) systems.
Mechanical and Physical Properties
Tensile strength runs from roughly 380 MPa for annealed Nickel 200 to 830 MPa and above for Inconel 625, with service temperatures reaching 1000°C in the solid-solution-strengthened grades.
Industry Applications
How round bar is used
Round bar is the starting stock for anything turned, milled or forged: pump and valve shafts, valve stems and seats, studs, bolting and fasteners, pins and bushings, and forged blanks for flanges and fittings. It is supplied hot rolled, forged, or cold drawn and centreless ground depending on diameter and the finish the machining route needs. Hollow bar and hex bar are the same material in a section chosen to save machining time.
| Industry | Typical use |
|---|---|
| Chemical processing | Reactor internals, heat exchangers and transfer piping handling acids, chlorides and caustics. |
| Oil and gas | Downhole tubing, wellhead components and sour-service equipment meeting NACE MR0175. |
| Power generation | Superheater and reheater elements, boiler tubing and flue-gas desulphurisation systems. |
| Aerospace | Engine casings, exhaust systems and airframe fasteners. |
| Marine | Seawater piping, condenser tubing and offshore platform hardware. |
Testing and Certification
Every consignment ships with an EN 10204 3.1 mill test certificate stating heat number, chemical analysis and mechanical properties. Depending on grade and specification we can supply positive material identification (PMI), ultrasonic and dye-penetrant testing, intergranular corrosion testing to ASTM A262 or G28, and third-party inspection release notes from Lloyd's Register, Bureau Veritas, SGS or TUV.
Aurico Alloys LLP operates an ISO 9001:2015 quality management system. Material for sour service can be supplied certified to NACE MR0175 / ISO 15156 where the grade permits.
Frequently Asked Questions
Request a Quotation
Send your grade, size, quantity and specification and we will respond with price and lead time, usually the same working day. Call +91 7977 88 6611 or email info@auricoalloys.com.
