Nickel 200 / 201 Foil Supplier, Stockist and Exporter
Aurico Alloys LLP supplies Nickel 200 and Nickel 201 Foil (UNS N02200 and N02201, ASTM B162) from ready stock in Mumbai.
Foil is where gauge consistency and surface cleanliness dominate, because at these thicknesses a rolling defect becomes a through-hole. Commercially pure nickel is chosen here for its combination of corrosion resistance, thermal and electrical conductivity, and reliable weld behaviour.
Sizes and Specifications
| Grades | Nickel 200 and Nickel 201 |
|---|---|
| Specification | One plate, sheet and strip specification per grade – listed in Equivalent Grades & Standards below. Inspection certificates to EN 10204. |
| Thickness | 0.01 mm to 0.50 mm |
| Width | 3 mm to 600 mm, slit to tolerance |
| Temper | Annealed (soft), half hard and hard |
| Finish | Bright annealed or matte, slit or deburred edge |
| Certification | EN 10204 3.1 mill test certificate |
| Price | INR 2,500 – 5,000 per kg. Indicative USD 29 – 59 per kg; quoted against grade, form, size and quantity. |
Equivalent Grades & Standards
Nickel 200
| Property | Value |
|---|---|
| UNS number | N02200 |
| Werkstoff / EN number | 2.4060 / 2.4066 |
| Density | 8.89 g/cm3 |
| Melting range | 1435-1446 °C |
| Specific heat | 456 J/kg·°C |
| Curie temperature | 360 °C |
| Plate, sheet and strip specification | ASTM B162 |
Identifiers and physical constants for Nickel 200. A dash means no such designation is published for this grade.
Nickel 201
| Property | Value |
|---|---|
| UNS number | N02201 |
| Werkstoff / EN number | 2.4061 / 2.4068 |
| Density | 8.89 g/cm3 |
| Melting range | 1435-1446 °C |
| Specific heat | 456 J/kg·°C |
| Curie temperature | 360 °C |
| Plate, sheet and strip specification | ASTM B162 / AMS 5553 |
Identifiers and physical constants for Nickel 201. A dash means no such designation is published for this grade.
Chemical Composition
Carbon is the distinguishing element between the two grades: the table below gives each grade its own limits, read off the mill bulletin named beneath it.
Nickel 200
| Element | Min (%) | Max (%) |
|---|---|---|
| Nickel (Ni) | 99.0 | — |
| Copper (Cu) | — | 0.25 |
| Iron (Fe) | — | 0.40 |
| Manganese (Mn) | — | 0.35 |
| Carbon (C) | — | 0.15 |
| Silicon (Si) | — | 0.35 |
| Sulfur (S) | — | 0.01 |
Composition limits for Nickel 200. These are specification limits for the grade, not measured values for a lot; the mill test certificate supplied with your order states the actual analysis.
Nickel 201
| Element | Min (%) | Max (%) |
|---|---|---|
| Nickel (Ni) | 99.0 | — |
| Copper (Cu) | — | 0.25 |
| Iron (Fe) | — | 0.40 |
| Manganese (Mn) | — | 0.35 |
| Carbon (C) | — | 0.02 |
| Silicon (Si) | — | 0.35 |
| Sulfur (S) | — | 0.01 |
Composition limits for Nickel 201. These are specification limits for the grade, not measured values for a lot; the mill test certificate supplied with your order states the actual analysis.
Mechanical and Physical Properties
Annealed tensile strength is around 380-450 MPa with elongation of 40% or more, and both grades have high thermal and electrical conductivity. Nickel 201 keeps its ductility in continuous service above 315 degrees C where Nickel 200 would embrittle. Density, melting range, specific heat and Curie temperature are in the Equivalent Grades table above rather than repeated here.
Industry Applications
| Industry | Typical use |
|---|---|
| Battery manufacturing | Cell tabs, interconnects and busbar stock for lithium packs. |
| Chemical processing | Caustic soda evaporators, vessel linings and handling equipment. |
| Electronics | Lead frames, shielding, anodes and precision stampings. |
| Aerospace | Gaskets, seals and corrosion-resistant shim stock. |
| Food processing | Equipment in contact with food-grade caustic and organic acids. |
